Model No: SZB2.1/25-D24/180
SZB Self-prming Solar Pump
Driven by solar energy, the photovoltaic arrays convert sunlight into electrical energy, which is then regulated and adjusted by the solar water pump inverter to power the self-priming pump. The pump utilizes its self-priming function to draw liquid from a low-level or low-pressure area and pump it to the desired height or pressure.
Quantity :
Self-priming refers to the pump's ability to draw liquid from a low-level or low-pressure area without the need for manual priming or pre-filling of liquid. This feature greatly simplifies the installation and operation process, enhancing convenience. The pump utilizes photovoltaic arrays (Solar Arrays) to convert solar energy into electrical energy, which then powers the pump motor. This drive method makes the pump highly valuable in sunny regions, especially remote and off-grid areas.
SZB Series Model List:
| Model | Pump | Solar Panels | Max Flow (m3/h) | Max Head (m) | Inlet/outlet Dia (inch) | ||
| Voltage(V) | Power(W) | VOC range(V) | Power(W) | ||||
| SZB2.1/25-D24/180 | 24 | 180 | 25-50 | 250-300 | 2.1 | 25 | 1x1 |
| SZB2.5/35-D24/300 | 24 | 300 | 25-50 | 500-600 | 2.5 | 35 | 1x1 |
| SZB3.2/40-D48/550 | 48 | 550 | 50-100 | 750- 1000 | 3.2 | 40 | 1x1 |
| SZB4.0/45-D48/750 | 48 | 750 | 50-100 | 1000-1250 | 4 | 45 | 1 x1 |
